PRSU4
Edge control unit Mat and strip mounted on DIN rail
Log in to access tariffs
Read on
Reinforced sensitive mat
ARMOR
Reinforced sensitive mat for control and safety applications in harsh environments.
Max Length: 2,400 mm - Max Width: 1200mm
COMPLIES WITH MACHINERY DIRECTIVE 2006/42/EC WHEN USED WITH OUR PRSU4 RELAY
Made to measure
Reliability: > 3 million pulses in a single point
Mats designed for safety applications in harsh industrial environments
Customisation: multi-zone, dimensions, sensitivity
Available in black or yellow
Voir Plus
-
Max Trigger force in N
-
Inactive Area Around Mats
-
Max Trigger force in Kg
-
Ingress Protection
-
Material
-
Response Time
Log in to access tariffs
LOG IN - NOT ONLINE - CONTACT US
| Selection criteria |
|
Choice of color ?
|
Authorisation(s) and certification(s)
Unfold Close2006/42/CE
Technical characteristics
Unfold Close| Product description : | Reinforced sensitive mat |
| Max Trigger force in N | 300 Newton |
| Max Trigger force in Kg | 30 Kilogram |
| Sensitivity | Low |
| Inactive Area Around Mats | 20 Millimeter |
| Activation Mode | Surface detection |
| Breaking capacity | 1 A |
| Response Time | 30 |
| Ingress Protection | IP65 |
| Max Operating Temperature | 50 Degree Celsius |
| Voltage - Current Type | VDC |
| Voltage | 24 |
| Cable Length | 2000 mm |
| Weight per square meter | 16.000 Kg/Square Meter |
| Depth / Thickness | 18.000 Millimeter |
| Material | KOROSEAL |
| Fixing mounting | Without fixing or with AE13 grommets |
