DM - ATEX UL manual trip switch

STEXCP8PB

High resistance GRP push button manual call point, designed for ATEX zones 1, & 2, and for the most severe environments.

Plus points

GRP housing, anti-corrosion
The rear part of the housing can be positioned so as to have the cable entries on the desired face
Protection class IP66 / IP67
Mechanism in stainless steel 316
Protective cover included
3 M20 inputs

Output in dB
Zones
Ingress Protection
Colour (material)
Material
Number of Tones

Selection criteria
Which kind of pole switch ? Validate cancel the current entry

Authorisation(s) and certification(s)

Unfold Close

IECEx & ATEX
II 2G Ex db IIC T6 Gb Ta. -55°C à +70°C
AUTRES
UL/ULc | NEC | Ex EAC | PESO CCOE

Technical characteristics

Unfold Close

Product description :	DM - ATEX UL manual trip switch
Output in dB	117 Decibel
Number of Tones	32
Ingress Protection	IP66
Min Operating Temperature	-50 Degree Celsius
Max Operating Temperature	70 Degree Celsius
Zones	Zones 1, 2, 21, 22
Relative Humidity	95% at 20°C
Cable entries	3 x M20 (Plugs and cable glands supplied)
Width	123.000 Millimeter
Height	217.000 Millimeter
Depth / Thickness	68.000 Millimeter
Weight	4.1 Kg
Material	Stainless Steel
Colour (material)	Red
